Single row four-point contact ball slewing bearing
Shandong Yongqiang Forging is a high-end manufacturing enterprise integrating forging blanks and slewing bearing processing. We are committed to providing various standard and non-standard slewing bearing solutions for the machinery industry. Slewing bearings are widely used in the machinery industry and provide excellent operating accuracy. They also do an excellent job in reducing weight, creating space, reducing friction, and extending service life. Yongqiang offers a variety of raw material materials, internal assembly options, lubricants and corrosion-resistant options. We provide slewing bearings with raceway center distances from 120mm to 2500. The sealing effect of our slewing bearing during operation effectively guarantees the internal lubrication of the slewing bearing and extends its service life. As a main engine supporting manufacturer of construction machinery, we can provide stable and reliable slewing bearing operation solutions.
Contact Us
Product Description

(01 series)





Note
1,n1is the number of lubricating oil holes. oil cupM10x1JB/T7940.1~JB/T7940.
2.The user can specify the position of the oil hole according to the application.,n-φ can be changed to threaded hole, thread diameterM, thread depth2M
3, The gear circumferential force in the table is the maximum circumferential force, and the rated circumferential force is taken as1/2.
4, "k” is the topping coefficient.
5, The specifications in this sample are standard products,Both inner and outer diameters are free tolerances. If there are cooperation requirements between the host machine and the slewing bearing, please specify them in the contract or contract attachments.(Such as technical agreement)Indicate the fit size and accuracy.
6. The products listed in the table are our company’s regular products. If you have other special requirements, please contact our company.
No. model Overall dimensions Installation Dimensions Structure Size Gear Parameters Peripheral force of gear Reference weight
De D d H D1 D2 n φ M n1 D3 d1 H1 h b m z x k Normalizing Tempering Kg
mm mm mm mm mm mm mm mm mm mm mm mm mm mm KN  KN
1 013.20.400.601 300 475   55 448 352 16 13.5 12 2 401 399 46 9 46 5 61 0.5 0 29 44 33
2 013.20.450.601 345 531   55 500 400 16 15.5 14 2 451 449 46 9 46 5 70 0.5 0 29 44 38
3 013.30.500.001 367 602 398 80 566 434 20 18 16 4 501 498 70 10 60 5 74 0.5 0.2 37 52 90
014.30.500.001 368.4 6 62 45 62 90
4 013.20.560.601 450 641   55 610 510 20 15.5 14 4 561 559 46 9 46 6 76 0.5 0 35 53 51
5 013.30.560.001 427 662 458 80 626 494 20 18 16 4 561 558 70 10 60 5 86 0.5 0.2 37 52 102
014.30.560.001 428.4 6 72 45 62 102
6 013.30.630.001 494.4 732 528 80 696 564 24 18 16 4 631 628 70 10 60 6 83 0.5 0.2 45 62 116
014.30.630.001 491.2 8 62 60 83 116
7 013.20.710.601 594 797   55 762 658 24 18 16 4 711 709 46 9 46 6 100 0.5 0 35 53 68
8 013.30.710.001 572.4 812 608 80 776 644 24 18 16 4 711 708 70 10 60 6 96 0.5 0.2 45 62 132
014.30.710.001 571.2 8 72 60 83 132
9 013.40.800.001 635.2 922 678 100 878 722 30 22 20 6 801 798 90 10 80 8 80 0.5 0.2 80 111 224
014.40.800.001 634 10 64 100 140 224
10 013.25.886.601 752 980   63 944 827 36 18 16 4 887 885 54 9 54 8 95 0.5 0 54 83 111
11 013.40.900.001 739.2 1022 778 100 978 822 30 22 20 6 901 898 90 10 80 8 93 0.5 0.2 80 111 252
014.40.900.001 734 10 74 100 140 252
12 013.40.1000.001 824 1122 878 100 1078 922 36 22 20 6 1001 998 90 10 80 10 83 0.5 0.2 100 140 292
014.40.1000.001 820.8 12 69 120 167 292
13 013.25.1077.601 930 1169   63 1134 1017 36 18 16 6 1078 1076 54 9 54 10 94 0.5 0 68 104 140
14 013.30.1120.601 960 1232   79 1188 1052 36 22 20 6 1121 1118 63 9 70 10 97 0.5 0 88 135 206
15 013.40.1120.001 944 1242 998 100 1198 1042 36 22 20 6 1121 1118 90 10 80 10 95 0.5 0.2 100 140 333
014.40.1120.001 940.8 12 79 120 167 333
16 013.30.1250.601 1090 1362   79 1318 1182 40 22 20 8 1251 1248 63 9 70 10 110 0.5 0 88 135 231
17 013.45.1250.001 1048.8 1390 1110 110 1337 1163 40 26 24 5 1252 1248 100 10 90 12 88 0.5 0.2 135 188 467
014.45.1250.001 1041.6 14 75 158 219 467
18 013.30.1400.601 1224 1512   89 1468 1332 44 22 20 11 1401 1398 63 9 80 12 103 0.5 0 121 176 296
19 013.45.1400.001 1192.8 1540 1260 110 1487 1313 40 26 24 5 1402 1398 100 10 90 12 100 0.5 0.2 135 188 529
014.45.1400.001 1195.6 14 86 158 219 529
20 013.40.1500.601 1308 1634   94 1582 1418 40 26 24 8 1501 1498 81 9 85 12 110 0.5 0 128 187 410
21 013.30.1600.601 1428 1712   89 1668 1532 48 22 20 8 1601 1598 63 9 80 12 120 0.5 0 121 176 334
22 013.45.1600.001 1391.6 1740 1460 110 1687 1513 45 26 24 5 1602 1598 100 10 90 14 100 0.5 0.2 158 219 607
014.45.1600.001 1382.4 16 87 181 250 620
23 013.40.1700.601 1498 1834   94 1782 1618 44 26 24 11 1701 1698 81 9 85 14 108 0.5 0 149 218 475
24 013.45.1800.001 1573.6 1940 1660 110 1887 1713 45 26 24 5 1802 1798 100 10 90 14 113 0.5 0.2 158 219 721
014.45.1800.001 1574.4 16 99 181 250 721
25 013.50.1800.601 1554 1971   109 1905 1695 36 33 30 9 1802 1798 99 9 100 14 112 0.5 0   257 762
26 013.50.2000.601 1764 2171   109 2105 1895 40 33 30 8 2002 1998 99 9 100 14 127 0.5 0   257 827
27 013.60.2000.001 1734.4 2178 1825 144 2110 1891 48 33 30 8 2002 1998 132 12 120 16 109 0.5 0.2 241 333 1265
014.60.2000.001 1735.2 18 97 271 375 1265
28 013.50.2240.601 1984 2411   109 2345 2135 48 33 30 8 2242 2238 99 9 100 16 125 0.5 0   294 961
29 013.60.2240.001 1990.4 2418 2065 144 2350 2131 48 33 30 8 2242 2238 132 12 120 16 125 0.5 0.2 241 333 1393
014.60.2240.001 1987.2 18 111 271 375 1393
30 013.50.2490.601 2240 2661   109 2595 2385 54 33 30 9 2492 2488 99 9 100 16 141 0.5 0   294 1053
31 013.60.2500.001 2239.2 2678 2325 144 2610 2391 56 33 30 8 2502 2498 132 12 120 18 125 0.5 0.2 271 375 1580
014.60.2500.001 2228 20 112 301 418 1580
32 013.50.2800.601 2544 2971   109 2905 2652 60 33 30 12 2802 2798 99 9 100 16 160 0.5 0   294 1205
33 013.60.2800.001 2527.2 2978 2625 144 2910 2691 56 33 30 8 2802 2798 132 12 120 18 141 0.5 0.2 271 375 1800
014.60.2800.001 2528 20 127 301 418 1800
34 013.75.3150.001 2828 3376 2922 174 3286 3014 56 45 42 8 3152 3147 162 12 150 20 142 0.5 0.2 377 522 2840
014.75.3150.001 2824.8 22 129 415 574 2840
